Stationary Compactor RamJet 5.5 Cubic Yard
Designed to Handle Heavy Industrial Manufacturing Waste Compaction
Mark-Costello’s RamJet RJ-575HD is a high capacity, heavy-duty compactor ideal for industrial and commercial applications where large volumes of solid waste are generated. Its rugged construction and large hydraulic power unit allow maximum compaction performance. The RJ-575 features a large 95″ x 59 1/2″ clear top opening to accommodate oversized crates and cartons.
Transfer Station…
The RJ-575HD is designed for transfer station applications for municipalities and private contractors. A conveniently located RJ-575HD transfer facility will eliminate the need for unnecessary trips to the landfill by intermediate collection vehicles resulting in fuel, maintenance and labor cost reductions. Compaction into large compaction containers or transfer trailers may also reduce dumping fees.
Industrial…
The high capacity, 5.5 cubic yard RJ-575HD is ideal for heavy industrial applications. The large hydraulic power unit and oversized clear top opening make it well suited for high volumes of pallets, crates and other bulky solid wastes.
This manufacturing facility utilizes a conveyor and a custom chute system to feed two, RJ-575HD Compactors with reinforced compaction containers.
Built to Last…
The heavy duty construction of the RJ-575HD features:
- 4″ I-beams reinforcement throughout
- Heavy duty ram with 3/4″ face plate & 3/8″ top
- Chrome allow ram guides and hardened steel wear strips for extended floor life
- Sides are constructed of 1/4″ thick steel with 3/8″ liner plates
- 4″x5″ boxed channel vertical side supports
- Hefty 6″x 8″x 3/4″angle breaker bar with 1″x12″steel plate reinforcement that easily handles the beating of daily industrial trash.
Ram Guide System
The packing ram is supported by specially formulated chrome allow wear shoes which ride on replaceable wear strips made of hardened steel. This exclusive design protects the charge box floor from the full force of the packing ram, extending its life and dramatically reducing compaction-robbing friction.
All of Mark-Costello’s RamJet 225 Series Compactors are Totally UL Listed!
Structural Dimensions
- Remote Power Unit
- Power Unit Weather Cover
- Heavy Duty Breaker Bar
- Ram
- Limit Switch
- Ram Guide Shoes with Replaceable Wear Strips
| A | B | C | D | E | F | G | H | I | J | K | L |
| 239 3/4″ | 69″ | 54″ | 60″ | 5″ | 33 1/2″ | 14 1/2″ | 43 1/2″ | 140″ | 99″ | 6″ | 39 7/16″ |
| 6090 mm | 1753 mm | 1372 mm | 1524 mm | 127 mm | 851 mm | 369 mm | 1105 mm | 3556 mm | 2515 mm | 152 mm | 1002 mm |
Specifications
| Charge Box Capacity | ||
| [Mfrs. Rating] | 5.5 cy | 4.21 m3 |
| [WASTEC Rating] | 4.23 cy | 3.23 m3 |
| Clear Top Opening | 95 1/2″ X 59 1/2″ | 2413mm x 1511mm |
Performance Data
| Cycle Time | 36 s | 36 s |
| Total Normal Force | 84,700 lb | 377 kN |
| Total Maximum Force | 96,200 lb | 428 kN |
| Normal Ram Face Pressure | 42.2 psi | 291 kPa |
| Maximum Ram Face Pressure | 48.0 psi | 331 kPa |
| Ram Penetration | 14″ | 356 mm |
Electrical Equipment
| Electrical Motor 3/60-208/230/460 | 30 hp | 22 kW |
| Electrical Control Voltage | 120 VAC | 120 VAC |
| UL Labeled Panel Box: Type NEMA 3R , All Circuits Fused | ||
| Standard 2 Button Controls: Keylock Start/ Mushroom Stop/Reverse Connected to 13′ Sealtite | ||
Hydraulic Equipment
| Hydraulic Pump Capacity | 52.0 gpm | 197 L/min. |
| Normal Pressure | 2200 psi | 152 bar |
| Maximum Pressure | 2500 psi | 172 bar |
| Hydraulic Cylinder | 7″ Bore x 4″ Rod | 178 mm x 102 mm |
| Weight | 12,600 lbs. | 5715 kg |
Pictures on this page are illustrative only. Specifications are ubject to change without notice to accommodate improvements to the equipment. Certified in compliance with ANSI Regulation Z245.2, all OSHA standards, and certified under WASTEC’s Stationary Compactor Certification Program. Products must be used with safe practice and in accordance with said regulations and standards.
The RJ-575HD can be fitted with a variety of material handling equipment such as chutes and cart dumpers. Cart dumpers can be custom built to your specifications to accommodate existing cart systems. Mark-Costello’s RJ-575HD is built tough to handle industrial applications and provide years of dependable service.
Optional Features Available
Visit our Options web pages to choose from a wide range of steel options, operational options and accessories including: multi-cycle timer, dual controls, ozone odor control system, security chutes, hoppers, cart dumpers and much more.
